VIA EPIA-M930 (1.8GHz VIA QuadCore)

VIA EPIA-M930 (1.8GHz VIA QuadCore)
  • Advanced I/O !
  • Mini-ITX !

Fast-track the development of embedded systems for the most demanding industrial and commercial usage scenarios with the VIA EPIA-M930 Mini-ITX board. Combining a 1.8GHz Intel® Celeron® quad-core processor with a wealth of I/O and connectivity features, including support for up to three displays, the VIA EPIA-M930 provides a flexible and reliable platform for myriad applications based on a compact Mini-ITX form factor.

Hardware
Powered by a 1.8GHz Intel® Celeron® quad core processor, the VIA EPIA-M930 Mini-ITX board accommodates up to 32GB system memory using its DDR4 SODIMM slot. The board supports up to three displays using one HDMI and two LVDS ports as wel [more]

Share

449.00 EUR
incl. 19% VAT, plus shipping
Available in 3 weeks
Add to cart

Fast-track the development of embedded systems for the most demanding industrial and commercial usage scenarios with the VIA EPIA-M930 Mini-ITX board. Combining a 1.8GHz Intel® Celeron® quad-core processor with a wealth of I/O and connectivity features, including support for up to three displays, the VIA EPIA-M930 provides a flexible and reliable platform for myriad applications based on a compact Mini-ITX form factor.

Hardware
Powered by a 1.8GHz Intel® Celeron® quad core processor, the VIA EPIA-M930 Mini-ITX board accommodates up to 32GB system memory using its DDR4 SODIMM slot. The board supports up to three displays using one HDMI and two LVDS ports as well as enabling flexible storage options through its SATA 3 and M.2 connectors. Additional I/O and networking features include up to four USB 2.0 ports, two USB 3.1 ports, up to four COM ports, one DIO for 8-bit GPIO, and dual Gigabit Ethernet connectors, as well as one SIM card, one PCIe, and two M.2 slots.

The functionality of the VIA EPIA-M930 Mini-ITX board can be enhanced using its onboard pin headers and a variety of Wi-Fi & Bluetooth, 4G LTE mobile broadband, and LTE mobile broadband & GPS M.2 modules.

Software
The VIA EPIA-M930 Mini-ITX board is compatible with Microsoft® Windows® 10, Microsoft® Windows® 11 and the most popular Linux distributions.

Model Name EPIA-M930
Processor1.8GHz Intel® Celeron® Quad Core processor
BIOSAMI UEFI BIOS, 256Mbit SPI Flash ROM
System Memory1 DDR4 SODIMM slot Up to 32GB memory
Storage1 SATA connector
1 M.2 slot
GraphicsIntegrated Intel Graphics Gen 11-Low Power (Gen 11-LP) Supports OpenCL* 1.2, OpenGL 4.5, OpenGL-ES 3.2, Vulkan. v1.1, DirectX
LAN2 Realtek RTL8111H -CG 10/100/1000M Ethernet controllers
AudioRealtek ALC888S-VD2-GR High Definition Audio Codec
Expansion I/O1 PCIe x1 slot
Onboard I/O1 SATA
1 USB 2.0 pin headers for 2 ports
2 Dual channel 18/24-bit LVDS panel connectors
2 COM port pin headers (powered with selectable 5V/12V)
1 I2C pin header
1 Digital I/O pin header (4 GPI + 4 GPO)
1 Front audio pin header for Line-out, Mic-in
1 Smart Fan pin headers for CPU and system
2 Backlight control connectors for inverter power and brightness control
1 RTC battery holder w/ battery
1 Clear CMOS jumper header
1 4-pin 12V DCIN power connector
1 PCIe x1 slot
1 M.2 slot for Wi-Fi 1 M.2 slot for storage/LTE
1 SIM card slot
Back Panel I/O1 HDMI port
2 COM port (powered with selectable 5V/12V)
2 Gigabit Ethernet port
2 USB 3.0 ports
2 USB 2.0 ports
3 Audio jacks: Line-in, Line-out, and Mic-in
Power Supply12V DC-in
Operating SystemWindows 10/11, Linux
System Monitoring and ManagementWake-on-LAN, System power management, Power failure recovery, Watchdog Timer, internal TPM, secure boot
Operating Temperature0°C ~ 60°C
Operating Humidity0% ~ 95% (non-condensing)
Form FactorMini-ITX (17cm x 17cm, 6.7" x 6.7")
ComplianceCE, FCC, UKCA
Data sheet Download (PDF)
Data sheet Print view
