NORVI EC-M11-EG-C1 (Programmable IoT Node, Wallmount)

NORVI EC-M11-EG-C1 (Programmable IoT Node, Wallmount)
  • ESP32-WROOM32 SoC inside !
  • Wallmount !
  • IP67 Rated Enclosure !
  • Wide Input Voltage Range !

NORVI SSN range is made for standalone installations in industrial environments, focused on monitoring sensor values or parameters from external devices. The wall mount and pole mount accessories, makes the implementations easy.

  • ESP32-WROOM32 SoC inside
  • GSM/LTE , NB-IoT , LoRa Expansions supported
  • Wide Input Voltage Range (9 – 36V DC)
  • Flexible I/O Combinations
  • IP67 Rated Enclosure
  • 1x Digital Input / 2 x Analog Input (0-10V DC)
  • 1x RS-485 Communication




Share

159.95 EUR
incl. 19% VAT, plus shipping
In Stock (22 pcs)

Add to cart
Main
Range of product Model 1
Product type Programmable node
Rated supply voltage Standard 9-36V DC
Field of Application Monitoring
Discrete Input Voltage 18-24V DC
Analog input range 0-10V DC
Communicaon RS-485
Complementary
Local signalling 1 LED green for PWR
1 LED red for Indication
Electrical connection Removable 8 pin connector / 3 meter cable supplied in standard package
Mounting support Wall mount Electrical Pole mount - accesory required
Height 100.00 mm
Depth 22.00 mm
Width 75.00 mm
Weight 0.22 kg
Environment
Relave humidity 10....95% without condensation in operation
IP degree of protection IP20
Operating altitude 0...2000m
Storage altitude 0...3000m
Shock resistance 15 gn for 11 ms
Operating temperature -40 to +85 °C
Data sheet Download (PDF)
Data sheet Print view
Datenblatt Download (PDF)
